Icom ID-31A Instruction Manual page 55

NOTE: The default settings, shown below, are for the USA version.
The default settings may differ, depending on the version.
Function (Continued) In this item, set other
CI-V CI-V Address
CI-V Baud Rate
CI-V Transceive
Display In this item, set the Display
Backlight
Backlight Timer
LCD Dimmer
LCD Contrast
Busy LED
RX Call Sign
options.
RANGE OR VALUE (Default is shown in bold)
01~84~DF
300, 1200, 4800, 9600, 19200 or Auto
OFF or ON
options.
RANGE OR VALUE (Default is shown in bold)
OFF, ON, Auto or Auto (DC IN:ON)
5sec or 10sec
Bright or Dark
1~8~16
OFF or ON
OFF, Auto or Auto (RX Hold)
MENU SCREEN OPERATION
DESCRIPTIONS
Sets the transceiver's unique CI-V hexa-
decimal address code.
Sets the CI-V code transfer speed.
Turns the CI-V Transceive function ON
or OFF.
DESCRIPTIONS
Selects the transceiver backlight option.
Selects the backlight ON time period.
Selects the LCD backlight brightness
level
Sets the contrast level of the LCD.
Turns the TX/RX indicator ON or OFF.
Selects the call sign display option when
receiving a call.
☞ Continued on the next page.
