Dimensions
mm (inches)
Net weight
Frequency range
Max SPL (max/cont)
Construction
AMPLIFIER
Type
Power Output
Dynamic Range
Input Clip
Bandwidth
Power Requirements
Connectors
TFA-600HDP
710 x 304 x 560
(28" x 12" x 22")
43kg (94.6lbs)
90Hz – 18kHz ±3dB
80Hz – 20kHz ±10dB
130dB/136dB
15mm birch ply
Class D inc. SMPA and
networked DSP
2500 watts @ 8 ohms
(1kHz, 0.01% THD)
110dB
10dBu
20Hz – 20kHz ±0.5dB
100V to 240V AC @50/60Hz
1 x XLR female input
1 x XLR male link
wired pin 2 hot
TFA-600LDP
574 x 710 x 848
(22.6" x 28" x 33.4")
75kg (165lbs)
38Hz – 150Hz ±3dB
30Hz – 150Hz ±10dB
133dB/139dB
15mm birch ply
Class D inc. SMPA and
networked DSP
2500 watts @ 8 ohms
(1kHz, 0.01% THD)
110dB
10dBu
20Hz – 20kHz ±0.5dB
100V to 240V AC @50/60Hz
1 x XLR female input
1 x XLR male link
wired pin 2 hot
user manual
FLEX ARRAY
TSW-218DP
574 x 1400 x 770
(22.6" x 55.1" x 30.3")
113kg (248.6lbs)
35Hz – 150Hz ±4dB
136dB/142dB
18mm birch ply
Class D inc. SMPA and
networked DSP
2500 watts @ 8 ohms
(1kHz, 0.01% THD)
110dB
10dBu
20Hz – 20kHz ±0.5dB
100V to 240V AC @50/60Hz
1 x XLR female input
1 x XLR male link
wired pin 2 hot
