Page 1: Tcs Series
TCS SERIES TCS-C50T Ceiling Speaker USER MANUAL Turbosound Ltd. Star Road, Partridge Green West Sussex RH13 8RY England Tel: +44 (0)1403 711447 Fax: +44 (0)1403 710155 www.turbosound.com Issue 1.1 August 2006 Copyright © 2006 Turbosound Ltd. -
Page 2: Table Of Contents
Cable Recommendations ...13 Servicing Information...14 Removal of the low frequency woofer ...14 Removal of the high frequency tweeter ...14 About EASE Data ...15 Overview ...15 Use of Turbosound EASE data...16 Technical Specifications...17 Spares List...18 Warranty...19 Notes ...21 TCS-C50T manual page 2... -
Page 3: Introduction
All TURBOSOUND products are carefully engineered for world class performance and reliability. If you would like further information about this or any other TURBOSOUND product, please contact us. Detailed product information is available on our web site at www.turbosound.com We look forward to helping you in the near future. -
Page 4: Product Summary
Paintable ABS speaker can be matched to a specific decor • TCS Series ceiling loudspeakers are fully supported with EASE polar data (available to download from the Turbosound web site at www.turbosound.com). This enables accurate and predictable results when specifying sound systems in a given venue. -
Page 5: Model Information
TCS Compact series Model Information Steel Fire can Tap Selector Loudspeaker Tweeter Attachment Screws Input Connector Strain Relief Fitting Terminal Cover Plate Rotating Mounting Tabs Perforated Grille TCS-C50T manual page 5... -
Page 6: Tcs-C50T
ABS ceiling frame with a perforated mesh grille. The TCS-C50T is rated at 75 watts r.m.s., and has a usable frequency range of 75Hz to 22kHz. It features a wide, conical dispersion pattern suitable for all high quality background music and speech applications. -
Page 7: System Considerations
(taking into account the individual power taps selected) connected to that particular amplifier channel. Turbosound recommends the T-series amplifiers for use with the TCS Compact series system. TCS-C50T manual... -
Page 8: Crossovers And Processors
TCS Compact series Crossovers and Processors The TCS-C50T is a passive loudspeaker system. This means that it requires only one amplifier channel for correct operation, the frequency splitting between the low frequency driver and the high frequency driver being accomplished by the internal passive crossover network. -
Page 9: Installation Procedure
In the unlikely event that the tile should come out or fall apart, the ends of the tile grid are designed to catch onto the T-grid, thereby preventing the loudspeaker from falling. user manual TCS Compact series Ø240 TCS-C50T manual page 9... - Page 10 Link Loop-through Terminals. All loudspeakers after this unit will be disconnected, helping to isolate problems to a section of the distributed line while leaving the wires connected to the connector. Link TCS-C50T manual page 10 Power Amplifier Power Amplifier Input...
- Page 11 10. Fit the loudspeaker grille. Orientate the grille such that the logo is facing in the desired direction, and press the grille firmly into place until it is flush with the rim. user manual TCS Compact series TCS-C50T manual page 11...
-
Page 12: Painting The Loudspeaker
It is advisable to spray the grille to avoid the mesh becoming clogged with paint from a roller or brush, which may impair the sound quality. Replace the grille cloth. TCS-C50T manual page 12... -
Page 13: Cable Recommendations
25.0 16.6 11.0 user manual Sensitivity Loss (dB) -0.1 -0.1 -0.1 -0.3 -0.4 -0.7 -0.7 -1.3 -1.3 -2.5 -0.1 -0.1 -0.2 -0.2 -0.4 -0.4 -0.8 -0.8 -1.6 -0.1 -0.1 -0.1 -0.1 -0.3 -0.3 -0.5 -0.5 -1.0 TCS-C50T manual page 13... -
Page 14: Servicing Information
Turbosound loudspeakers. Removal of the low frequency woofer The perforated steel loudspeaker grille is a push fit in the loudspeaker frame. To remove the grille, using a pointed object such as a pin inserted through the mesh of the grille, gently lever the grille away from the frame. -
Page 15: About Ease Data
Sound system projects are more likely to go to plan when you have a reliable indicator in advance of how the speaker system will perform in the venue. Turbosound engineers are able to assist you with your system design using the industry-standard EASE program to aid in the quest to find the perfect system for the job. -
Page 16: Use Of Turbosound Ease Data
TCS Compact series Use of Turbosound EASE data Turbosound provides pre-measured EASE data to aid sound system designers in making appropriate choices with the type and positioning of speakers in the required venue. The suitability of certain models can be assessed and the installation can be improved by adapting the frequency response consequently. -
Page 17: Technical Specifications
16 ohms nominal Paintable injection moulded ABS plastic Powder coated perforated steel Phoenix 4-way connector for input and link Thermal fuse disconnects speaker from distributed system Without back can (TCS-C50TS) without back can or transformer (TCS-C50S) user manual TCS-C50T manual page 17... -
Page 18: Spares List
TCS Compact series Spares List Spares LF Driver HF Tweeter Passive Crossover Network Grille Tile bridge TCS-C50T manual page 18 LS-50 5” loudspeaker TW-52 tweeter PX-TCS-C50T MG-C50 TCS-C50TB... -
Page 19: Warranty
The product serial number must be quoted in all correspondence relating to the claim. Insurance is recommended, as Turbosound or its representatives are not liable for loss or damage in transit. Turbosound will pay for return freight costs should repairs be covered under warranty. - Page 20 TCS Compact series Incidental and consequential damages Turbosound's liability is limited to the repair or replacement, at our option, of any defective product, and shall not be liable for any incidental and consequential damages including, without limitation, injury to persons or property or loss of use.
-
Page 21: Notes
TCS Compact series Notes TCS-C50T manual page 21...
