FLEX ARRAY

Appendix A: Technical Specifications

Dimensions
mm (inches)
Net weight
Frequency range
Dispersion
Power handling
(continuous)
Sensitivity (1w@1m)
Max SPL (max/cont)
Crossover points
Nominal impedance
Construction
Connectors
FLEX ARRAY user manual
Page 78
TFA-600H
710 x 304 x 560
(28" x 12" x 22")
41kg (90.2lbs)
90Hz – 18kHz ±3dB
80Hz – 20kHz ±10dB
75°H x 16°V
LF: 600 watts
MF: 120 watts
HF: 60 watts
LMF: 96dB
HMF: 108dB
HF: 104dB
130dB/136dB
Bi-amp 90Hz, 600Hz
Tri-amp 90Hz, 600Hz, 6kHz
LF: 8 ohms
MF: 8 ohms
HF: 8 ohms
15mm (5/8")
birch plywood
2 x NL8
TFA-600L TSW-218
710 x 574 x 848 574 x 1400 x 770
(28" x 22.5" x 33.4") (22.6" x 55.1" x 30.3")
72kg (158.4lbs) 110kg (242lbs)
40Hz – 100Hz ±3dB 35Hz – 150Hz ±4dB
35Hz – 100Hz ±10dB
N/A N/A
800 watts 1600 watts
104dB 104dB
133dB/139dB 136dB/142dB
90Hz 150Hz
8 ohms 4 ohms
15mm (5/8") 18mm (5/8")
birch plywood birch plywood
2 x NL4 2 x NL4
