user manual
FLEX ARRAY
9. Adjust the overall inclination of the cluster using a speed brace or electric drill applied to
the 22mm (7/8") drive nut at the rear of the flybar. An inclinometer may be used on the
flybar or the top cabinet to obtain a consistent angle between the left and right PA
clusters.
10. Lock the lift point with BLP-10/100 100mm (4") locking pin before lifting the flybar into its
final position.
FLEX ARRAY user manual
Page 44
