FLEX ARRAY user manual
Page 20
Using USB
Connect your computer to the BvNet interface using a USB Type A to USB Type B
cable. External power is not required when using USB.
USB
Connect network devices in a simple daisy-chain fashion with CAT5 type cables in
the order you want them to appear in the devices window.
Launch the TurboDrive™ software
On the first launch, the application will prompt for an authorisation code. The code
is PJLUWZ
Select the COM port from Network > Com Port
Click the Online toolbar button
Click on one of the devices that appear in the tree view to Launch the Panel
CONTROLLER
IN
LINK
CONTROLLER
IN
LINK
BVNET INTERFACE
IN
LINK
RS-232
USB
