user manual
FLEX ARRAY
Connection to the first TFA-600H cabinet is made via two 10mm ball-lock pins which are
engaged into the rear spine of the mid/high cabinet (one pin is located on the loudspeaker
and one pin is located on the conversion frame).
The drop link from the TFA-600L low frequency cabinet is released by removing one of the
pins and pivoting the link into the conversion frame.
The drop link from the conversion frame locates into the clevis connection plate of the top
mid/high cabinet in one of several predetermined locations, which allows for a range of inter-
cabinet angles.
FLEX ARRAY user manual
Page 41
