- Page 1 ASPECT TA-500 SYSTEMS TA-500 TA-500DP TA-500t TA-500tDP TA-500H TA-500HDP TA-500HM USER MANUAL Turbosound Ltd. Star Road, Partridge Green West Sussex RH13 8RY United Kingdom Tel: +44 (0)1403 711447 Fax: +44 (0)1403 710155 web: www.turbosound.com Issue 1.1 © Turbosound Ltd.
-
Page 2: Table Of Contents
Overview...17 Safety Notes on Rigging ...18 Secondary Safeties ...19 Safety Inspections...19 Sample Certificate of Load Test ...21 Flying Hardware...22 Aspect TA-500 Flying Systems ...22 Horizontal Coverage ...22 Vertical Coverage...22 A. TA-500t Touring Flying System ...23 TA-500 user manual Page 2... - Page 3 Attaching the biscuit...32 Attaching the Tilt Straps...33 Lifting the column ...34 B. TA-500 Install Flying System...36 Rigging Instructions...37 Flying a single TA-500 cabinet using M10 eyebolts ...41 LMS series Loudspeaker Management Systems ...42 Introduction ...42 Unpacking...42 Mechanical Installation...42 LMS-D24 and D26 Loudspeaker management Systems ...43...
- Page 4 Parametric filters ...55 Output Channels ...56 Gain and Polarity...56 Delay ...56 High and Low Pass Filters ...57 Parametric Equalisation ...58 Limiters ...59 Routing...59 Utilities ...60 Utility functions ...60 T-25 and T-45 High Efficiency Audio Power Amplifiers ...61 TA-500 user manual Page 4...
- Page 5 Gain and Sensitivity Settings...66 Attenuation & Gain Setting...67 Output Connections...67 Damping Factor...67 Long Speaker Lines ...68 The Cooling System ...68 Appendix A: Technical Specifications ...69 Appendix B: Spare Parts List ...71 Appendix C: Warranty ...72 user manual TA-500 TA-500 user manual Page 5...
-
Page 6: User Manual Ta
Relevant Specifications used as basis for tests Category Professional apparatus for use in Commercial Light Industrial and controlled EMC environments. CE Marking All products are marked in accordance with the relevant statutory requirements. TA-500 user manual Page 6 EN60065:2003 EN66103-1:1996 EN55103-2:1996... -
Page 7: Introduction
The TA-500 trapezoidal enclosure can be ground-stacked or flown in arrays. It can also be integrated with TA-880 or TA-890 systems as a front or side fill cabinet. -
Page 8: The Aspect Polyhorn™ Concept
Because of the Polyhorn™ design’s sharp cut-off, its array angle can in practice be taken as being the same as the dispersion angle. Fig 1. Conventional HF horns produce destructive interference TA-500 user manual Page 8 Fig 2. Poyhorn™ creates smoothly curved and phase-coherent wavefront... - Page 9 • The TA-500 features approximately twice the horizontal and vertical dispersion as the narrower TA-880 and TA-890 products, making it more suitable for medium- and near-field applications in smaller rooms. • The Polyhorn™ displays a similarly sharp cut-off at the dispersion edges to the...
-
Page 10: The Loudspeaker Management System (Lms) Concept
BvNet protocol using Turbosound’s TurboDrive™ software, available as a free download from the Turbosound website For a detailed explanation of TA-500 networking capability please consult the TurboDrive™ User Guide, available in pdf as a download from our ftp site ftp://ftp.turbosound.com. -
Page 11: Power Amplifiers
Power Amplifiers In addition to the Turbosound T-25 and T-45 model amplifiers recommended for use with Aspect systems, the following other power amplifier brands provide sufficient performance and mechanical compatibility to perform well with Aspect loudspeaker systems: • MC2 E series •... - Page 12 Neodymium magnets are used throughout all drive units. This results in higher efficiency, less power compression and reduced overall weight. Low-mid frequency drivers are designed to be rear-facing in the enclosure, enabling the heatsink / phase plug to be placed in the air flow to aid cooling. TA-500 user manual Page 12...
-
Page 13: Ta-500 Three-Way Loudspeaker
It is configured as a switchable tri-amped or bi-amped (with passive high end) product. The TA-500 is equipped for flying in fixed installations with an external flying system. TA-500DP Self-powered Three-way Loudspeaker The TA-500DP is a networkable, digitally self-powered version of the TA-500, and contains a Turbo-loaded neodymium 15"... -
Page 14: Ta-500H Horizontal Three-Way Loudspeaker
Class D amplifier module. TA-500H Horizontal Three-way Loudspeaker The TA-500H is a horizontally-orientated version of the TA-500 with the mid/high section rotated through 90° in order to maintain a 50° horizontal by 25° vertical dispersion pattern housed in a rectangular enclosure. -
Page 15: B18 Subwoofer
The B18 is a compact bandpass subwoofer designed to be used in a variety of installed sound system applications as well as portable sub-bass support for Aspect TA-500 enclosures. It consists of a high-excursion, 4” voice-coil, 18” LF driver in a bandpass birch plywood enclosure of modest dimensions. -
Page 16: Transportation
An optional WB-500 wheelboard is available which clips on to the front of the cabinet, allowing single units to be conveniently transported. These are designed to be stackable, so that when not in use they can be neatly stored without taking up unecessary floor space. TA-500 user manual Page 16... -
Page 17: Flying And Stacking
Obtain a smooth even curve in the horizontal plane. • Use a similar amount of tilt on each column. • Ensure that the bottom corners of each column are in line with each other. user manual TA-500 TA-500 user manual Page 17... -
Page 18: Safety Notes On Rigging
Only use Turbosound recommended rigging accessories, which are specifically designed for their intended purpose. Do not use Turbosound rigging with other types or brands of loudspeakers. This practice may compromise safety standards and Turbosound will not be responsible for damage or injury so caused. -
Page 19: Secondary Safeties
Users must ensure compliance with all applicable safety requirements. Turbosound recommends regular safety inspections and further recommends that a logbook be kept detailing the test and inspection history of each Turbosound rigging accessory. Turbosound has adopted the following load safety factors: •... - Page 20 The Lifting Operations and Lifting Equipment Regulations 1998 Each component is covered by a Record of Load Test Certificate, which may be obtained on request from Turbosound, quoting the indentifying number(s) from the flying equipment. A copy of a sample certificate is reproduced overleaf.
-
Page 21: Sample Certificate Of Load Test
TA-500 Sample Certificate of Load Test TA-500 user manual Page 21... -
Page 22: Flying Hardware
Because the Polyhorn’s design dramatically reduces the acoustic energy outside of the specified 50° horizontal dispersion pattern, it is recommended that Aspect TA-500 enclosures always be arrayed in a smooth even curve, resulting in an array angle of 50° between boxes. -
Page 23: User Manual Ta
A two-wide, three deep cluster can be flown from a single half-tonne motor using a CB-8003 chain bridle. Rugged lifting eyes are used preventing damage to lifting points and ensuring ease of connection. user manual TA-500 TA-500 user manual Page 23... - Page 24 Figure 2: Flybar Lifting Points and Dimensions Two columns of enclures can be flown from the FB-500T/2W flybar. Additionally a single column facility is provided allowing the flying of a single column of enclosures. TA-500 user manual Page 24 PICKUP POINT...
-
Page 25: Table 1: Flying Matrix
21° Single 42° Single As required Narrow 7°, 14° Narrow 21° Wide 14°, 28° Wide user manual TA-500 Angle between rows FC-500T Standard FC-500T Standard FC-500T Long FC-500T Standard FC-500T Standard FC-500T Standard FC-500T Long TA-500 user manual Page 25... - Page 26 60kg. Two inter-cabinet chain sets plus one top chain set provides the facility for lifting a maximum of three rows of enclosures. FC-500T Long Flying Chain Net weight is 1kg (2.2lbs) FC-500T Standard Length Flying Chain Net weight is 1kg (2.2lbs) Inter-cabinet Link Net weight is 0.5kg (1.1lbs) TA-500 user manual Page 26...
-
Page 27: Ts-890 Tilting Straps
All parts of the flygear are fitted flush with the woodwork of the cabinet, and can quickly and easily be removed for safety testing using a Torx TX20 bit. The following diagram decribes the various parts of the flygear. TA-500 user manual Page 27... -
Page 28: Bolt
A captive biscuit is included in the cabinet, retained by a spring-loaded ball bearing. The component is designed to tie the backs of the cabinets together, whilst allowing up to 21° of vertical angle between rows. TA-500 user manual Page 28 Bolt... -
Page 29: Connecting Flying Chains To The Cabinet
The bolt slides back along its runner enabling the placing of the profile into the slot. The bolt is spring loaded to ensure that when in its closed position (as shown below) it is free from vibration and cannot be damaged. Bolt Slot Figure 4: Locking Mechanism TA-500 user manual Page 29... -
Page 30: Sliding The Top Chain Profile Into The Slot
Sliding the top chain profile into the slot The profile is positioned into the slot so that the ‘wings’ bear on the top of the integral flygear assembly. Figure 5: Assembly of the Top Chains to the Cabinet TA-500 user manual Page 30... -
Page 31: Connection Of Additional Rows
The enclosures are stacked on the ground in appropriate positions to allow easy lifting with the flybar. The inter-cabinet link chains are attached from the outside of the cabinets using a similar procedure to the top chain assembly. Figure 6: Adding additional rows TA-500 user manual Page 31... -
Page 32: Setting The Angles Between Rows
Once the inter-cabinet chains have been connected both sides, the captive biscuit must be engaged. To do this, the biscuit is pushed out of its holder in the upper cabinet into the upper kelping bracket of the lower cabinet: TA-500 user manual Page 32... -
Page 33: Attaching The Tilt Straps
In any event it is essential that all personnel in the vicinity are aware that the system is about to move and that they must keep clear. SAFETY NOTE: Turbosound flying systems have been designed and constructed to a high standard of safety and tested to the most demanding of specifications with a high safety factor. -
Page 34: Lifting The Column
Using the appropriate lifting point on the flybar, attach the bridle and lift ensuring during the lifting process that the column lifts evenly. Figure 10: Front view of the assembled cluster Figure 11: Rear view of the assembled cluster TA-500 user manual Page 34... - Page 35 TA-500 TA-500 user manual Page 35...
-
Page 36: Ta-500 Install Flying System
B. TA-500 INSTALL FLYING SYSTEM The flying system is designed to provide the following configurations of flown arrays: Number of Rows The Aspect TA-500 install flying hardware consists as follows: • Enclosure connector – attaches to the top of a row of cabinets •... -
Page 37: Rigging Instructions
TA-500 Rigging Instructions STEP 1 - Set the boxes out on the floor with the sides touching. Remove the M10 blanking screws from the rear of the boxes at top and bottom as illustrated. TA-500 user manual Page 37... - Page 38 STEP 3 – Fit the enclosure connector to the top of the array. Locate the four M10 eyebolts from the fixings kit supplied and insert these through the enclosure connector into the rigging points on the centre cabinet. These will be used to pick up the array. TA-500 user manual Page 38...
- Page 39 Use the four M10 x 35mm hex screws from the fixings kit to lock the enclosure connector to the rear brace together with four flat washers and four M10 nylock nuts. All fixings should be thread-locked and torqued to 25Nm. TA-500 user manual Page 39...
- Page 40 The two rear eyebolts are provided as safety points. Ensure all components are assembled using lock-tight. The total cluster weight including rigging hardware is approximately 210 kgs (462 lbs). TA-500 user manual Page 40...
-
Page 41: Flying A Single Ta-500 Cabinet Using M10 Eyebolts
Flying a single TA-500 cabinet using M10 eyebolts The simplest method of flying a TA-500 cabinet is with a pair of M10 shoulder eyebolts on the top, using a third eyebolt on the rear of the cabinet to tilt the cabinet. -
Page 42: Lms Series Loudspeaker Management Systems
Unpacking As part of Turbosound's system of quality control, the product is carefully checked before packing, to ensure flawless appearance. After unpacking the unit, please inspect for any physical damage. If any damage has occurred, please notify your dealer immediately, so that a written claim for damages can be initiated. -
Page 43: Lms-D24 And D26 Loudspeaker Management Systems
Extended bandwidth; 96kHz sampling frequency provides for a nominally flat response to 40kHz. • Front panel parameter rotary encoder provides a familiar and easy to use control format with all filter information displayed simultaneously on a backlit LCD display. user manual TA-500 TA-500 user manual Page 43... -
Page 44: Front Panel Functions
Edit Select Buttons – the currently selected edit parameter is displayed on the bottom left corner of the LCD. Pressing the edit select buttons moves through the available parameters for the current input or output. TA-500 user manual Page 44 2x 24 character... - Page 45 XLRs and the RS232 port. When activated, this will disable all the front panel controls so they cannot affect the signal path, making the unit secure against tampering. When in secure mode, the indicators still operate normally. Note that the communications port is still active in secure mode. TA-500 user manual Page 45...
-
Page 46: Rear Panel Functions
This port is also used for updating the firmware in the unit. Note: The communications port is NOT disabled when the front panel is made secure using the secure button. TA-500 user manual Page 46 Secure Mode Network Card... -
Page 47: Operating The Lms-D24 And D26
Selecting a Factory Preset There is a library of thirty Factory Presets to suit a range of Turbosound enclosures. Factory Presets contain some parameters that are fixed and hidden from view; the remainder of the DSP parameters are available for user manipulation. -
Page 48: Navigation And Viewing Parameters
Turn a knob clockwise to increase the value of a parameter, or anti-clockwise to decrease it. The knobs are velocity-sensitive so turning a knob rapidly will cause the action to ‘accelerate’, so the value changes more rapidly. TA-500 user manual Page 48 In A Freq... -
Page 49: Navigation
NB. When the unit powers-up, the settings will be the same as those when the unit was last switched off. LMS-D26 Out1 Freq Width 100Hz 1.4Q user manual TA-500 Gain 0.0dB TA-500 user manual Page 49... -
Page 50: Presets
Presets but they have some parameters that are predefined as a function of the loudspeaker system. These parameters are ‘hidden’ from the user, as they should be constant regardless of application. TA-500 user manual Page 50 Preset Name Recall 32... -
Page 51: Preset Store
NAME PRESET The user can overwrite non-protected Presets only; if an attempt is made to save a Preset in a location already occupied by a basic or Factory Preset a ‘LOCKED PRESET’ message is displayed. TA-500 user manual Page 51... -
Page 52: Dsp Processing Layout
Outputs 2 (routed from L input) and 4 (routed from R input) [2 and 5 for LMS-D26] • Outputs 3 (routed from L input) and 6 (routed from R input) – LMS-D26 only] TA-500 user manual Page 52 Input Order... -
Page 53: Dsp Processing
The velocity sensitive Parameter Knobs therefore provide accurate setting of driver offset delays (typically below 10ms) and rapid setting of longer system alignment delays. LMS-D26 LMS-D26 user manual TA-500 TA-500 user manual Page 53... - Page 54 For example 18dB / octave Linkwitz-Riley filters do not exist. The Hardman type filter is always described by its’ order as the filter becomes progressively steeper rather than following a linear slope so a dB/octave description is not accurate. TA-500 user manual Page 54 In A Freq Shape 20.0Hz LR24...
-
Page 55: Parametric Equalisation
BW adjustable from 0.05 to 5 octaves in variable steps Q adjustable from 14.2 to 0.2 in variable steps Knob C, Gain, +/-15dB in 0.2dB steps LMS-D26 Slope Gain 12dB 0.0dB LMS-D26 Width Gain 1.4Q 0.0dB user manual TA-500 TA-500 user manual Page 55... -
Page 56: Output Channels
Delay Knob A: Adjustable in variable steps from 0 to 80ms As for input delay, velocity sensitive Parameter Knobs provide finer adjustment at low levels and rapid selection of higher values. TA-500 user manual Page 56 Out1 Gain 0.0dB Out1 Delay 1.50ms... -
Page 57: High And Low Pass Filters
The Hardman type filter is always described by its’ order as the filter becomes progressively steeper rather than following a linear slope so a dB/octave description is not accurate. LMS-D26 Shape LR24 user manual TA-500 TA-500 user manual Page 57... -
Page 58: Parametric Equalisation
Knob B, Width, display selectable, Q or BW (Bandwidth) BW adjustable from 0.05 to 5 octaves in variable steps Q adjustable from 14.2 to 0.2 in variable steps Knob C, Gain, +/-15dB in 0.2dB steps TA-500 user manual Page 58 Out1 Freq Slope EQ>- 100Hz... -
Page 59: Limiters
Inp A Knob A: Output source, selectable; Input A, Input B or Sum A+B Configures the routing from input to output. This function is only available in mono format Presets. LMS-D26 LMS-D26 user manual TA-500 TA-500 user manual Page 59... -
Page 60: Utilities
LCD changes. The screen contrast utility control sets the base contrast of the screen and also allows optimization for a given viewing angle. Parametric equalisation width parameters can be displayed in either ‘Q’ or bandwidth, expressed in octaves. Util Screen ParaEQ TA-500 user manual Page 60 LMS-D26 100% BW=Q... -
Page 61: T-25 And T-45 High Efficiency Audio Power Amplifiers
High damping factor, >400 below 1kHz. • Low noise vari-speed fans for quiet operation. • Front-panel accessible filter for improved dust collection. • Consistent reliability and easy serviceability through solid, lightweight construction and modular packaging. user manual TA-500 TA-500 user manual Page 61... -
Page 62: Front Panel Functions T-25
PRC – green LED indicates when the PRC for that channel has been selected. • Bridge (BRG) – green LED illuminates when bridge mode is selected. • Fault (A/P) – red LED indicates protection circuit activity. TA-500 user manual Page 62 Ch. A Ch.B... -
Page 63: Front Panel Functions T-45
PRC – green LED indicates when the PRC for that channel has been selected. • Bridge (BRG) – green LED illuminates when bridge mode is selected. • Fault (A/P) – red LED indicates protection circuit activity. Ch. A Ch.B user manual TA-500 TA-500 user manual Page 63... -
Page 64: Mechanical Installation
The Green/Yellow wire on the T-25 and T-45’s mains cord must always be connected to the electrical installation's safety Earth (or Ground). It is essential for personal safety. The rack framework is connected to the same grounding circuit. TA-500 user manual Page 64... -
Page 65: Voltage Setting
Pin 3 The shield connection to pin 1 at each amplifier input must be maintained under all circumstances, as TURBOSOUND will not be responsible for consequential damage arising to loudspeakers, etc., should this connection not be made. The amplifiers are designed to operate with fully balanced equipment. Ground loops or loss... -
Page 66: Polarity
A and GAIN B - are situated on the input PCB (PCB701). A jumper link sets the gain and the settings are as follows: NOTE: Factory setting is normally link 1 & 2 = 32dB gain. TA-500 user manual Page 66 Screen - connect to chassis of the unbalanced equipment,... -
Page 67: Attenuation & Gain Setting
Damping factor is maximised by installing cables containing conductors of large cross- sectional area, and by specifying connectors with heavy-duty contacts and waterproof covers. The cable sets supplied with Aspect systems are manufactured to a high specification with these considerations in mind. TA-500 user manual Page 67... -
Page 68: Long Speaker Lines
There are 4 fans connected permanently with variable speed and a jumper link to enable them from cold. Normal dynamic signals will not cause the amplifier to overheat unless the ventilation is inadequate. (See installation section and maintenance section.) TA-500 user manual Page 68... -
Page 69: Appendix A: Technical Specifications
250Hz – 20kHz 50°H x 25°V MF: 200 watts HF: 100 watts MF: 105dB HF: 112dB 135dB/141dB MF: 250Hz – 5kHz HF: 5kHz – 20kHz MF: 16 ohms HF: 16 ohms 15mm birch ply 3 x NL8MP TA-500 user manual Page 69... - Page 70 Net weight Frequency range (±4dB) Power handling (continuous) Sensitivity (1w@1m) Max SPL (max/cont) Nominal impedance Construction Connectors TA-500 user manual Page 70 TA-500tDP 977 x 574 x 498 (38.5 x 22.6 x 19.6) 59kg (130lbs) 60Hz – 18kHz 50°H x 25°V...
-
Page 71: Appendix B: Spare Parts List
10” High-mid driver 15” Low-mid driver Compression driver Recone kit Recone kit Replacement diaphragm TA-500 grille (with foam, badge and inserts) Inter cabinet links Top chain assembly standard length Top chain assembly long Tilt strap user manual TA-500 TA-500 user manual... -
Page 72: Appendix C: Warranty
This warranty does not affect any statutory rights of the purchaser. Should any fault develop with a component of your Turbosound system the faulty unit should be sent, in its original packaging, to the supplier or your local authorised Turbosound dealer with the shipping prepaid. - Page 73 TA-500 Turbosound Limited Star Road Partridge Green West Sussex RH13 8RY United Kingdom TA-500 user manual Page 73...
