Button
1 Voicemail Flashing red light indicates there is a
Indicator voicemail on the phone.
2 The home key returns you to the Home
Screen of the phone. Pressing it twice
returns you to the idle screen.
Full Color Color Touch Screen. Touch sensitive,
3 Touch Screen full color screen that allows you to tap
to highlight and select, or scroll using
up down left and right movements.
Headset Key- Light is green with the
use of an analog headset and Blue when
4
using a USB headset.
5 Speakerphone Key – Glows green
when in use.
6 Mute Key- Glows red when in use.
7 Volume up and down key
8 Microphone Transmits sound without using the
handset, this is an audio input device.
9 Speaker Transmits sound without using the
handset, this is for audio output.
Allows entery of numbers, letters and
other characters, also allows for
10 Dial Pad
selection of numbered menu items.
