Appendix : i9P Technical Specification
General
Approvals
CE – conforms to EU Directive 89/336/EEC
FCC – verified to CFR47:Part 15
Dimensions
Satellite antenna unit 113cm (44.6") x 121cm(47.5")
Antenna dish diameter 85cm(33.5")
Antenna control unit 17.8cm(7")x21.7cm(8.5")x5.4cm(2.1")
Weight
Satellite antenna unit 56.2kg (123.8 lbs)
Antenna control unit 1.2kg (2.6 lbs)
Environmental
Operating temperature range -25°C to +55°C (-13°F to 131°F)
Storage temperature range -30°C to +70°C (-22°F to 158°F)
Humidity limit 95% R.H
Power requirements 9~30 V DC
Power consumption Typ. 30W, Max. 50W
60
Antenna system performance
Frequency
Minimum EIRP
Azimuth range
Elevation range
Ship's motion
Roll and pitch
response rate
Turn rate
Ku-band (10.7 to 12.75 GHz)
44 dBW
680°
-15° ~ +90°
Roll ±25°
Pitch ±15°
30° per second
30° per second
