Auto LNB Skew Angle Adjustment

Intellian i9P has an embedded auto skew angle control system.
Skew sensor
Therefore, manual adjustment of the skew angle is not required. The
LNB
skew angle is continuously adjusted automatically through calculations
of the optimum angle by using the information of a targeted satellite
and the GPS position. With location information as ship's longitudinal
and latitudinal position change from movement the skew angle will be
adjusted accordingly. As the ship changes position, the skew angle will
be continuously adjusted. The skew angle of the LNB is shown on the
ACU and in the GUI program.
Skew motor
Figure 16 : Auto LNB Skew Angle Control System
19
