Basic System Configuration
For your satellite TV system to work properly, the system will have to be
connected with all of the provided components properly, as shown in
the figure below (see the "Installation" section of this manual). Separate
purchase of a satellite receiver and a TV is required.
Note: Dish Network and Bell TV users please refer to the Intellian Dish
Network MIM Installation and User Manuals.
ACU
ANT RF1
FG - +
+ -
DC 9 - 30 V FUSE ANTENNA NMEA
9-30V DC Power
NMEA GPS PC Cable
Figure 01 : Basic System Configuration
IRD 2 (Not supplied)
(Optional)
IRD 3 (Not supplied)
(Optional)
IRD 4 (Not supplied)
(Optional)
TV (Not supplied)
RECEIVER
PC INTERFACE
Satellite Receiver (IRD)
