Normal Mode

Start Up
With the system installed and power applied, the ACU screen will show
the following sequence:
INITIALIZE ACU
INTELLIAN i9P
INITIALIZE ANTENNA
INTELLIAN i9P
SEARCH A: DTV101
B:DTV119 SETUP
TRACKING A: DTV101
B:DTV119 SETUP
1. Data communication is being established
between the antenna and the ACU. The ACU
is initialized.
2. The antenna is initialized.
3. The antenna is searching for Satellite A.
4. The antenna has located the satellite and is
now tracking.
Changing Target Satellite
Your antenna is pre-programmed with either two (Dual-Sat mode) or
three (Tri-Sat mode) candidates of target satellites as a default mode.
To change a target satellite, press LEFT soft key. The target satellite is
changed and is automatically tracked by the antenna.
Default Dual-Sat Mode
TRACKING A: DTV101
B: DTV119 SETUP
TRACKING B: DTV119
A: DTV101 SETUP
1. Press LEFT soft key for tracking
Satellite B.
2. The antenna is tracking Satellite B.
21
