BASIC OPERATION
■ Receiving and transmitting (Continued)

D Transmitting notes

• Transmit inhibit function
The transceiver has several inhibit functions which restrict
transmission under the following conditions:
- The channel is in the 'Inaudible' (mute) mode ("
does not appear.)
ble icon)
- The channel is busy. However, depending on the pre-
programmed settings, you can transmit when a call is re-
ceived that includes an unmatching (or matching) CTCSS
(DTCS), colour code, or Individual or Talkgroup ID.
- The selected channel is a 'receive only' channel.
• Time-out timer
If continuous transmission exceeds the pre-programmed
time-out timer limit, the transmission is cut off.
• Penalty timer
After the transmission is cut off by the time-out timer, trans-
mission is further inhibited for the pre-programmed penalty
timer period.
11

D TX code channel selection

If the transceiver has a key assigned to TX Code CH Select,
the indication can be toggled between the operating channel
number (or name) and TX code channel number (or name).
" When the TX code channel number (or name) is displayed,
(Audi-
[CH Up] or [CH Down] selects the TX code channel.
USING [TX CODE CH SELECT]:
q Push [TX Code CH Select]— a TX code channel number
(or name) appears.
w Push [CH Up] or [CH Down] to select the desired TX code
channel.
e After selecting, push [TX Code CH Select] to set.
• Return to the stand-by mode.
r Push [Call] to transmit the selected TX code.
USING [TX CODE CH UP]/[TX CODE CH DOWN]:
If the transceiver has a key assigned to TX Code CH Up or
TX Code CH Down, the programmed TX code channel can
be directly selected when pushed.
