Icom iF5062D Instruction Manual page 11

C.TONE CH ENT
Push to enter the continuous tone channel selection mode.
Then push [CH Up] or [CH Down] to select the desired tone
frequency/code setting. The selected channel remains set
until another channel is designated.
TALK AROUND
Push to turn the Talk Around function ON or OFF.
• The Talk Around function equalizes the transmit frequency to the
receive frequency for transceiver-to-transceiver communication.
WIDE/NARROW
Push to toggle the IF bandwidth between Wide, Mid* or
Narrow.
• The wide passband width is preprogrammed to either 25.0 or 20.0
kHz by your dealer (PMR operation only).
*Depending on the preprogrammed settings, Mid channel width may
not be selectable. Ask your dealer for details.
DTMF AUTODIAL
Push to enter the DTMF channel selection mode, then push
[CH Up] or [CH Down] to select a desired DTMF channel.
After selecting, push again to transmit the selected DTMF
code.
RE-DIAL
Push to transmit the last-transmitted DTMF code.
• TX memories are cleared after turning the power OFF.
PANEL DESCRIPTION
CALL, CALL A, CALL B
Push to transmit a 2/5-tone code or BIIS/dPMR call.
• Call transmission is necessary before calling another station,
depending on your signalling system.
• [Call A] and/or [Call B] may be available when your system employs
selective 'Individual/Group' calls. Ask your dealer which call is
assigned to each key.
EMERGENCY
Hold down for the pre-programmed time period to enter the
emergency mode. After the pre-programmed time period, an
Emergency call is transmitted once, or repeatedly*. (p. 14)
• To exit the emergency mode, hold down this key for the pre-pro-
grammed time period again, before transmitting.
* Depending on the pre-programmed settings.
SURVEILLANCE
Push to turn the Surveillance function ON or OFF.
When this function is turned ON, the beep does not sound
and the LCD backlight and the LED indicator do not light,
even when a signal is received or a key is pushed.
TX CODE ENTER
Push to enter the TX code edit mode (5Tone) (p. 12) or the
ID code edit mode (BIIS, dPMR), and then set the desired TX
code or ID code.
