1
PANEL DESCRIPTION
■ Programmable function keys (Continued)
TX CODE CHANNEL SELECT
➥ Push to enter the TX code channel selection mode (p. 11)
or the ID selection mode (BIIS, dPMR), and then push
[CH Up] or [CH Down] to select the desired channel or ID.
➥ Hold down this key for 1 second to enter the TX code
edit mode (5Tone) (p. 12) or the ID code edit mode (BIIS,
dPMR), and then set the desired TX code or ID code.
TX CODE CHANNEL UP, TX CODE CHANNEL DOWN
Push to select a TX code channel (p. 11) or ID (BIIS, dPMR).
SCRAMBLER
Push to turn the Voice Scrambler function ON or OFF.
COMPANDER
Push to turn the Compander function ON or OFF.
The Compander function reduces noise components from the
transmitted audio to provide clear communication.
ID-MR SELECT
➥ Recalls detected ID codes.
• Push this key, then push [CH Up] or [CH Down] to select the ID
code.
• Up to 5 IDs are memorized.
➥ Hold down for 1 second to erase the selected ID.
7
HOOK SCAN
When the Hook Scan function is pre-programmed, push this
key to disable the function. Push this key again to enable the
function.
USER SET MODE
➥ Hold down for 1 second to enter the User Set mode.
• In the User Set mode, push this key to select an item that is ena-
bled by your dealer, and change the value or setting by pushing
[CH Up] or [CH Down].
➥ Hold down for 1 second again to exit the User Set mode.
10Key ENT
Push to enable the microphone's 10-keypad operation.
• Depending on the pre-programmed settings, 10-keypad can be
used to select a desired memory channel, ID list number (dPMR),
TX status (BIIS, dPMR) or Short Data Message (dPMR), or enter a
desired TX code (5-tone) or ID (dPMR).
OPT 1 OUT, OPT 2 OUT, OPT 3 OUT
Push to output the control signal to the option connector. Ask
your dealer for details.
