Tx Code Channel Selection; Manual 5-Tone Codes; Transmitting Notes - Icom IC-F30GT Instruction Manual

5
CONVENTIONAL OPERATION

' ' Tx code channel selection

Your radio may be programmed for Tx code channel selection. In
this case, you can choose a Tx code channel to be transmitted
when using the call function (p. 17).
Push [Tx Code CH Up/Down] (assigned to one of the dealer-pro-
grammable switches) to select the desired Tx code channel.
• The selected code channel (containing a pre-programmed 5-tone
code) is transmitted when using the call function.

' ' Manual 5-tone codes

Depending on programming, you may be able to send 5-tone codes
manually.
Push [Tx Code] to activate the function, then enter the desired
transmit code (up to 7 digits) using the keypad.
• Activate the call function to transmit the 5-tone code.
• Blinking indicates keypad entry is acceptable.

' ' Transmitting notes

D D TIME-OUT TIMER
After continuous transmission for a pre-programmed period, the
time-out timer is activated, causing the transceiver to stop trans-
mitting.
D D PENALTY TIMER
Once the time-out timer is activated, transmission is further in-
hibited for a period determined by the penalty timer.
18
