1
PANEL DESCRIPTION

■ Programmable function keys

The following functions can be assigned to [UP], [DOWN],
[P0], [P1], [P2], [P3] and [P4] programmable function keys.
Consult your Icom dealer or system operator for details con-
cerning your transceiver's programming.
If the programmable function names are bracketed in the fol-
lowing explanations, the specific key is used to activate the
function, depending on the pre-programmed settings.
INFORMATION:
Depending on the pre-programmed settings, the pro-
grammed function for [P0], [P1], [P2] or [P3] is assigned
to [A], [B], [C] or [D] of the optional HM-152T, respec-
tively. Ask your dealer for details.
CHANNEL UP, CHANNEL DOWN
➥ Push to select an operating channel.
➥ As described in the following topics, after pushing a pro-
grammed key, push [CH Up] or [CH Down] to select an
option, setting, etc.
3
ZONE
Push this key, then push [CH Up] or [CH Down] to select the
desired zone.
What is "zone"?—Certain channels are grouped together
and assigned to a zone, according to their intended use.
For example, 'Staff A' and 'Staff B' are assigned to a "Busi-
ness" zone, and 'John' and 'Cindy' are assigned to a "Pri-
vate" zone.
ZONE UP, ZONE DOWN
Push to select an operating zone.
SCAN
➥ Push to start or cancel a scanning operation.
• When a scan is started by the Power ON Scan or Automatic
Scan function, push this key to cancel the scan. The cancelled
scan resumes after the pre-programmed time period.
➥ Hold down this key for 1 second to display the scan group,
then push [CH Up] or [CH Down] to select the desired
one.
