Operation; Normal Wash Mode - CMA Dishmachines UC65e Installation & Operation Manual

Follow the instructions below to operate the dishwasher in a Normal Wash Mode. A Safe-T-Temp feature
holds the dishwasher in a wash mode if the booster heater temperature is below 180ºF/82ºC.
1. Turn the main power on at the main circuit breaker.
2. Install the sump filter, overflow tube and spray arms.
3. Make sure the flexible drain hose and the flexible fill hose are not kinked,
then turn the water supply on.
4. Close the dishwasher front door.
5. Push the dishwasher Power Switch to the ON position.The power switch will illuminate and the
machine will fill with water.
6. Check the pressure gauge as the machine fills and make sure the incoming water pressure is
between 20-22 psi.
7. Wait 15-minutes for the WASH temperature gauge to indicate a minimum of 150ºF/66ºC.
At the beginning of the day, run 2 empty cycles before checking the final rinse
operating temperature. The first cycle will take longer than normal because the
8. Load soiled wares into the dish rack. Place plates, glasses, cups and bowls in a peg rack.
Place utensils in a single layer in a flat-bottom rack. Place pots and pans in a flat-bottom rack.
Do not overload the dish racks.
9. Slide 1 dish rack into the wash compartment making sure that wares do not interfere with the
rotating spray arms. Do not wash more than 1 dish rack at a time.
10. Close the front door fully, then press and hold the START BUTTON for 1-second. The green
in-cycle light will illuminate and the wash cycle will begin. The wash cycle time runs for
approximately 1-1/2 minutes. (continued on next page)
20-22 PSI
20
10
0
Final Rinse
Pressure
ATTENTION
water temperature in the booster is low.
30
40
PSI
50
CHAMPION INDUSTRIES, INC.
WINSTON-SALEM,NC
60
The pressure and temperature gauges are located on the lower-left corner
of the lower-front access panel.
150°F/66°C
120
40
60
20
80
0
100
Wash
Temperature

Operation

Normal Wash Mode

180-195°F
82-91°C
120
40
60
20
80
0
100
Final Rinse
Temperature
13
