Clearing jams
2
Lift the green handle, and then pull the toner cartridge out of the printer.
3
Place the cartridge aside.
4
Lift the green handle, and then pull the imaging unit out of the printer.
5
Place the imaging unit aside on a flat, smooth surface.
Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes.
Extended exposure to light may cause print quality problems.
Warning—Potential Damage: Do not touch the photoconductor drum. Doing so may affect the print quality of
future print jobs.
6
Pull the jammed paper gently to the right, and then remove it from the printer.
Note: Make sure all paper fragments are removed.
2
1
