Learning about the printer
The staple, hole punch finisher must not be combined with any other output option.
In a configuration with two or more optional finishers:
•
The staple finisher must always be on top.
• The high‑capacity output expander must always be at the bottom.
•
The output expander is the only option that can be placed on top of the high‑capacity output expander.
•
The output expander and mailbox may be installed in any order.
When using optional trays:
•
Always use a caster base when the printer is configured with a 2100‑sheet tray.
•
The 2100‑sheet tray must always be at the bottom of a configuration.
•
A maximum of four optional trays may be configured with the printer.
•
The optional 250‑ and 550‑sheet trays may be installed in any order.

Using the printer control panel

Use the
1 Display
2 Select button
3 Arrow buttons
4 Keypad
5 Sleep button
6 Stop or Cancel button Stop all printer activity.
1
10
9
To
•
View the printer status.
•
Set up and operate the printer.
Submit changes made in the printer settings.
Scroll up and down or left and right.
Enter numbers, letters, or symbols.
Enable Sleep mode or Hibernate mode.
Do the following to wake the printer from Sleep mode:
•
Press any hard button.
•
Pull out Tray 1 or load paper in the multipurpose feeder.
• Open a door or cover.
• Send a print job from the computer.
•
Perform a power‑on reset with the main power switch.
•
Attach a device to the USB port on the printer.
3
2 4
5
6
8 7
12
