How to Select the Paper Path

The paper can be loaded into the printer using different paper paths. The messages
indicating the paper paths are shown only if the corresponding loading device is
installed on the printer.
Proceed as follows:
1. Press the ON LINE key to put the printer offline (ON LINE indicator unlit).
2. Press the PATH key, according to the installed devices the following messages
To load fanfold paper go to "Loading Paper Using the Front1 Push Tractor" on
page 88 and "Loading Paper Using the Front2 Push Tractor (option)" on page 112.
When a new paper path is selected, the paper loaded in the printer is
automatically parked.

How to Use the Tear-Off Function

This function is used to match the paper perforation with the tear-off bar. For this
function the following values must be set:

Selection of the Paper Size

1. Press the PROGRAM key when the printer is disabled or enabled without
2. Press the ↓ key and the following message appears:
3. Press the
4. Once the desired macro is displayed press the
5. Press the
6. Press again the PROGRAM key to exit the setup end set the new value.
are displayed:
LOAD FRONT 1 For the paper path using the Front1 push tractor.
LOAD FRONT 2 For the paper path using the Front2 push tractor option
printing to enter the Program Setup.
USER MACRO
key to select the macro for which you want to set the paper size
(MACRO#1, MACRO#2, MACRO#3 or MACRO#4).
parameter is displayed:
LENGTH xx
or key until the desired page size is displayed.
key until the following
Chapter 3. Configuring the Printer
79
