3.5 SP Ramp Set Up Group
Introduction
A single setpoint ramp [SPRAMP] can be configured to occur between the
current local setpoint and a final local setpoint over a time interval of from 1 to
255 minutes.
SPRATE lets you configure a specific rate of change for any local setpoint
change.
You can also configure a 12-segment program from a Ramp/Soak profile.
You can start and stop the ramp/program using the RUN/HOLD key.
PV Hot Start is standard and means that at power up, the setpoint is set to the
current PV value and the Ramp or Rate or Program then starts from this value.
Function Prompts
Table 3-4 SPRAMP Group (Numeric Code 300) Function Prompts
Prompt
English
Numeric
Code
301
SP RAMP
301
TI MIN
FINLSP
302
SPRATE
304
305
EUHRUP
306
EUHRDN
SPPROG
307
STRSEG
308
4/00
Description
Single Setpoint
Ramp
Rate and Program
must be disabled
Single Setpoint
Ramp Time
Setpoint Ramp Final
Setpoint
Setpoint Rate
Ramp and Program
must be disabled
Rate Up
Rate Down
Setpoint Ramp/Soak
Programming
Rate and Ramp
must be disabled
Start Segment
Number
UDC2300 Universal Digital Controller User Manual
Selection or Range of Setting
Numeric
English
Code
0
DIS
1
ENAB
0 to 255 Minutes
Enter a value within the
setpoint limits
0
DIS
1
ENAB
0 to 9999 in Engineering
units per hour
0 to 9999 in Engineering
units per hour
0
DIS
1
ENAB
1 to 11
Table continued next page
Configuration
Factory
Setting
DIS
3
1000
DIS
0
0
DIS
- - -
25
