that are attached with straps of fabric; be careful that the pieces do not swing out and hurt
you or anybody else.
3. Extend the ramps to their full length, if necessary, as shown in
Figure 2-2 Ramp Extension and Installation
4. Attach the ramps by fitting the metal prongs into the holes on the pallet. Line up the arrows
on the ramps with the arrows on the pallet, as shown in
or mallet to ensure a firm connection.
5. Remove the shipping bolts and brackets (see
40 Unpacking and Assembling the Racks
Left
unloading
ramp
Right
unloading
ramp
Extend ramp to
full length
Figure
Shipping
pallet
Right ramp
attaches here
ZK-2084
Figure 2-2. If necessary, use a hammer
Figure 2-3) that hold the rack on the pallet.
2-2.
