Unpacking Space; Thee-Rack Cluster Footprint - HP Cluster Platform Introduction v2010 Introduction Manual

Table 1-7 42U Rack Dimensions and Weight (continued)
Metric
Width (footprint)
Weight (empty)
Maximum weight
1 For both dynamic and static loading considerations.
The footprint dimensions include the distance spanning the leveling feet and the additional
width dimensions of optional side panels. Use this information to estimate the total closed-rack
floor space required by your configuration and the corresponding floor-loading value. For
example, a configuration that consists of three racks with two end panels requires 1.843 square
meters (19.845 square feet).
configuration.
Note:
The figure below uses 600 mm wide cabinets. The 42U, 800 mm wide cabinet is not shown in
this footprint example.
Figure 1-3 Thee-Rack Cluster Footprint
The footprint denotes the physical dimensions of the system; it does not include additional space
around the racks required for service access and airflow, described in
Section 1.5.4 (page

1.5.2 Unpacking Space

When planning for the installation, also plan for the additional space needed to unpack the rack
and remove it from its shipping pallet. If there is insufficient space in the computer room, you
might need to clear some space in an anteroom or corridor and then roll the system to its
installation destination. The following considerations might be relevant:
• You need 122-cm (48-in) of clearance all the way around the pallet and above the rack to
allow the removal of the packing materials.
• Maintain at least 86-cm (34-in) of clearance in front of the rack to allow the door to open all
the way.
Unpacked Characteristics
603 mm 24 in
114.84 kg 253 lb
1
Figure 1-3
72"
182.2cm
19.84sq feet
1.84sq meters
25).
Shipping Characteristics Packed on Shock Pallet Model
B22
813 mm
129 kg
907.18 kg
illustrates the footprint required for a three-rack
39.69"
100.81cm
HPTC-0004
32 in
284 lb
2000 lb
Section 1.5.3 (page 24)
1.5 Physical Layout Requirements
and
23
