Figure 1-1 Maximum Rack Configuration Using a 1:1 Ratio of HP SFS20 Enclosures to ProLiant
DL360 Object Storage Servers
Expansion
Rack 2
Expansion
Rack 4
Object Object
Storage Storage
Servers Servers
50 - 63 22 - 35
SFS20
SFS20
Enclosures
Enclosures
SFS20-22A,
SFS20-50A,
SFS20-51A, SFS20-23A,
SFS20-24A,
SFS20-52A,
SFS20-25A,
SFS20-53A,
SFS20-26A,
SFS20-54A,
SFS20-27A,
SFS20-55A,
SFS20-56A, SFS20-28A,
SFS20-29A,
SFS20-57A,
SFS20-30A,
SFS20-58A,
SFS20-31A,
SFS20-59A,
SFS20-32A,
SFS20-60A,
SFS20-61A, SFS20-33A,
SFS20-34A,
SFS20-62A,
SFS20-35A
SFS20-63A
For more configuration examples, see the HP StorageWorks Scalable File Share manuals.

1.3 Site Preparation and Planning Overview

Read the following topics in conjunction with the technical specifications included in the
appendixes of the online cluster documentation. See the Preface section titled
location of the online documentation. Information in this section is intended to help HP customers
and HP Global Deployment representatives to prepare an installation plan and schedule any
necessary site work. For example, it might be necessary for you to make physical modifications
to your site before you can receive the cluster for installation.
A cluster is delivered as pre-configured building block modules installed in HP model 10000-series
racks, usually a 42U (2-meter) rack. For some configurations, a shorter rack model might be
employed. The building block modules are packaged and mounted on shock pallets for shipping.
In addition to the information in this chapter, you should consult the following resources,
particularly if you are unfamiliar with the HP 10000 series rack or with the process of receiving
preconfigured systems:
• Online information for the HP rack 10000 Series is located at the following URL:
http://h18000.www1.hp.com/products/servers/platforms/rackandpower.html
• Best Practices for HP 10000 Series and HP 10000 Series G2 is available at the following location:
http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00637362/c00637362.pdf
Expansion
Rack 1
Expansion
Rack 3
Base Rack
MDS &
Admin
Servers
SFS20
Enclosures
SFS20-M0A,
SFS20-M0B,
SFS20-M1A,
SFS20-M1B
HP
ProCurve
Switch
1, 2, 3
Object
Object Object
Storage
Storage Storage
Servers
Servers Servers
36 - 49
0 - 7 8 - 21
SFS20 SFS20 SFS20
Enclosures Enclosures Enclosures
SFS20-00A, SFS20-08A, SFS20-36A,
SFS20-01A, SFS20-09A, SFS20-37A,
SFS20-02A, SFS20-10A, SFS20-38A,
SFS20-03A, SFS20-11A, SFS20-39A,
SFS20-04A, SFS20-12A, SFS20-40A,
SFS20-05A, SFS20-13A, SFS20-41A,
SFS20-06A, SFS20-14A, SFS20-42A,
SFS20-07A SFS20-15A, SFS20-43A,
SFS20-16A, SFS20-44A,
SFS20-17A, SFS20-45A,
SFS20-18A, SFS20-46A,
SFS20-19A, SFS20-47A,
SFS20-20A, SFS20-48A,
SFS20-21A SFS20-49A
1.3 Site Preparation and Planning Overview
Section for the
