AT810 Series User Manual
symbols, such dials will be rejected.
2. It will wait for input if there are more than one rule match user's enters.
3. It will send the number directly if the input is timeout.
4. It will send the number directly if user presses the key "#".
 Syntax
1. "x": Stands for a digit range from 0 to 9.
2. "[]": Stands for a range.
For examples: [389] stands for 3 or 8 or 9;
[3-6] stands for 3 or 4 or 5 or 6;
[235-8*] stands for 2 or 3 or 5 or 6 or 7 or 8 or *.
3. ".": Stands for the previous one digit could be repeated. For example "01.", the
numbers match this rule are 01, 011, 0111,...and so on.
4. "<>": The replace rule. For example: "<8:1650>xxxxxxx" stands for any
numbers begin with 8 and the length is 7, the first 8 will be replaced by 1650 and
dialed out then. Such as dialing 8551212, the phone will dial 1650551212 at last.
5. ",": Stands for playing an outside dial tone. For example "9,1xxxxxxxxxx", user
will hear an outside dial tone when user press the first key "9" until the following
key "1" is been pressed.
6. "!": Stands for the number which is forbidden to dial. For example
"137xxxxxxxx!" stands for forbidding user to dial numbers whose length is 11 and
begin with 137.
For example:
Set the dial plan as (xxxxxxx|[*#]xxxx|9,1xxxxxxxxxx|00xxx!).
The syntax above contains 4 rules:
1. Allow dialing numbers whose length is 7.
2. Allow dialing numbers whose length is 4 and begin with * or #.
3. User will hear an outside dial tone when user press the first key "9", and then a
number whose length is 11 and begin with 1 will be dialed out.
4. Forbid dialing Numbers whose length is 5 and begin with 00.
The following dial plan accepts only US style 1 + area code + local number, with no
restrictions on the area code and number.
(1 xxx xxxxxxx)
The following also allows 7-digit US-style dialing, and automatically inserts a 1 + 212
(local area code) in the transmitted number.
(1 xxx xxxxxxx | <:1212> xxxxxxx)
For an office environment, the following plan requires a user to dial 8 as a prefix for local
calls and 9 as a prefix for long distance. In either case, an "outside line" tone is played
after the initial 8 or 9, and neither prefix is transmitted when initiating the call.
(<9, :> 1 xxx xxxxxxx | <8,:1212> xxxxxxx )
