Location
Function
The fifth and sixth locations of the output definition provide the time base multiplier. Enter a value between
368 to 397
01 and 99.
Outputs
(continued) One Shot Mode
When you program the output polarity as one shot, the time base is multiplied by the time base multiplier.
For example, if the time base = 2 and the multiplier = 05, the output operates for 5 sec.
Pulsing Mode
When you program the output polarity as pulsing, the time base becomes the ON time and the multiplier
becomes the OFF time. The OFF time is the time base, which is multiplied by the multiplier. For example,
if you want the output to pulse 1 sec ON and 5 sec OFF, you would program time base as 2 and the
multiplier as 5.
398 to 399
Entry Time 1
Refer to page 70
400 to 401
Entry Time 2
Refer to page 71
402 to 403
Exit Time (AWAY/STAY Modes)
Refer to page 71
404 to 405
Entry Guard Time for STAY Mode
Refer to page 71
406 to 407
Delay Alarm Report Time
Refer to page 71
408 to 409
Sensor Watch Time
Refer to page 71
410
Codepad Lockout Time
Refer to page 71
411
Siren Run Time
Refer to page 71
412
Siren Sound Rate
Refer to page 71
413
Auto Arming Pre-Alert Time
Refer to page 71
414 to 417
Auto Arming Time
Refer to page 72
418 to 421
Auto Disarming Time
Refer to page 72
422
Kiss-Off Wait Time
Refer to page 72
423
Reserved
424
System Options 1
Refer to page 73
Bosch Security Systems, Inc. | 12/08 | F01U089401-02
ICP-CC404 | Installation Guide | 22.0 Programming Sheets
Options/Notes
Location 398: increments of 1 sec (0 to 15 sec)
Location 399: increments of 16 sec (0 to 240 sec)
Location 400: increments of 1 sec (0 to 15 sec)
Location 401: increments of 16 sec (0 to 240 sec)
Location 402: increments of 1 sec (0 to 15 sec)
Location 403: increments of 16 sec (0 to 240 sec)
Location 404: increments of 1 sec (0 to 15 sec)
Location 405: increments of 16 sec (0 to 240 sec)
Location 406: increments of 1 sec (0 to 15 sec)
Location 407: increments of 16 sec (0 to 240 sec)
Location 408: increments of days (tens digit)
Location 409: increments of days (units digit)
0 No lockout
1 to 15 Increments of 10 sec (10 sec to 150 sec)
0 No siren time
1 to 15 Increments of 1 min (1 min to 15 min)
0 to 15 (slowest to fastest frequency)
0 No pre-alert time
1 to 15 Increments of 5 min (5 min to 75 min)
Location 414: Hour of day (tens digit)
Location 415: Hour of day (units digit)
Location 416: Minute of day (tens digit)
Location 417: Minute of day (units digit)
Location 418: Hour of day (tens digit)
Location 419: Hour of day (units digit)
Location 420: Minute of day (tens digit)
Location 421: Minute of day (units digit)
0 to 15 Increments of 500 ms (500 ms to 8 sec)
1 Bosch smart lockout allowed
2 Horn speaker monitor
4 Strobe indication for radio arm/disarm
8 Horn speaker beeps for radio arm/disarm
Default/
Programming Entry
4 1
8 2
12 3
0 0
0 0
0 0
0
5
7
1
0 0 0 0
0 0 0 0
3
0
1
