ICP-CC404 | Installation Guide | 22.0
Location
Function
267 to 322
Zone Definitions
Refer to page 54
Zone #01
(267 to 273)
Zone #02
(274 to 280)
Zone #03
(281 to 287)
Zone #04
(288 to 294)
The first location (from the left) of the zone definition is the Zone Type. The options are:
0 Instant
1 Handover
2 Delay 1
3 Delay 2
The second location of the zone definition is the Zone Pulse Count. Use the pulse count to program the
number of pulses (0 to 15) that must register within the pulse count time to activate an alarm.
The third location (from the left) of the zone definition is the Zone Pulse Count Time. The options are:
0 0.5 sec
1 1 sec
2 2 sec
3 3 sec
The fourth location of the zone definition is the Zone Options 1 parameter. The options are:
1 Lockout siren/dialer
2 Delay Alarm Report
The fifth location of the zone definition is the Zone Options 2 parameter. The options are:
1 Isolated in STAY Mode 1
2 Zone isolation allowed
The sixth location of the zone definition is the Report Code. The options are:
0 Do not send Zone Alarm Reports
1 Send Zone Alarm Reports
The seventh location of the zone definition is the Zone Dialer Options parameter. The options are:
0 No Zone Reports allowed
1 Report to Receiver 1
2 Report to Receiver 2
The keyswitch zone options replace Zone Options 1 for zones programmed to operate as keyswitch
zones (Zone Type = 11). The options are:
0 Latching arm and disarm in AWAY Mode
1 Latching arm in AWAY Mode
2 Latching disarm from AWAY Mode or
4 Latching arm and disarm in STAY Mode
5 Latching arm in STAY Mode
6 Latching disarm from STAY Mode
88
Programming Sheets
2 0 0 1 14 1 1
(Delay 1)
1 0 0 1 14 1 1
(Handover)
1 0 0 1 14 1 1
(Handover)
0 0 0 1 14 1 1
(Instant)
4 Reserved
5 Reserved
6 24-hour medical
7 24-hour panic
20 ms Loop Response Time:
4 4 sec
5 5 sec
6 10 sec
7 15 sec
STAY Mode
Options/Notes
Zone #05
(295 to 301)
Zone #06
(302 to 308)
Zone #07
(309 to 315)
Zone #08
(316 to 322)
8 24-hour hold-up
9 24-hour tamper
10 Reserved
11 Keyswitch
150 ms Loop Response Time:
8 20 sec
9 30 sec
10 40 sec
11 50 sec
4 Silent alarm
8 Sensor watch
4 Forced arming allowed
8 Zone Restore Report allowed
4 Report to both Receiver 1 and Receiver 2
8 Report to Receiver 2 only if Receiver 1
fails
8 Momentary arm and disarm in AWAY
Mode
9 Momentary arm In AWAY Mode
10 Momentary disarm from AWAY Mode or
STAY Mode
12 Momentary arm and disarm in STAY Mode
13 Momentary arm in STAY Mode
14 Momentary disarm from STAY Mode
