Table 33:

Point ID Codes

Point ID
Zones 1 to 8
User Specific 1 to 16
040
031
User Specific 1 to 16
041
046
045
042
044
047
Zone Specific 1 to 8
Zone Specific 1 to 8
Zone Specific 1 to 8
00
10.1.2 Point ID Codes
Table 33 on page 43 shows the different Point ID
Codes and Event Codes that are sent to the base
station receiver when using Contact ID Reporting
Format. All Event Codes are fixed. The control panel
always sends the same code because there are no
programming locations to change the codes.

10.1.3 4 + 2 Express Reporting Format

The 4 + 2 Express Format reports a Subscriber ID
Number followed by an Expansion Code. The
reporting Channel Number is sent directly after the
Expansion Code.
Table 34: Example Reporting in 4 + 2 Express
Format
Subscriber ID Expansion
Number Code
SSSS A
Bosch Security Systems, Inc. | 12/08 | F01U089401-02
ICP-CC404 | Installation Guide | 10.0 Dialer Reporting Formats
Event Description
Burglary Zone
Medical Zone
Panic Zone
Hold-Up Zone
Tamper Zone
Burglary Zone
Fire
Open/Close Report
AC MAINS Fail
Low Battery
Codepad Duress
Codepad Panic
Codepad Fire
Codepad Medical
Code Retry Limit Exceeded
Test Report
Test Report
Sensor Watch
Trouble
Bypass
AUX Power Supply Fail
Channel
Number
C
H
Event Code Explanation
130 Burglary
100 24-Hour Medical
120 24-Hour Panic
122 24-Hour Hold-Up
137 24-Hour Tamper
133 24-Hour Burglary
110 24-Hour Fire
401 Opening – User #
Closing – User #
301 AC Power
309 Battery Test Failure
121 Duress Alarm
120 Panic Alarm
110 Fire Alarm
100 Medical Alarm
421 Access Denied
602 Test Report
602 Test Report
307 Sensor Self Test Failure
380 Sensor Trouble
570 Zone Bypass
300 System Trouble
Table 35: 4 + 2 Express Reporting Format
New Event 4 + 2 Report
Alarm SSSS AC
Trouble SSSS TC
Bypass SSSS BC
AC Fail SSSS EA
Low Battery SSSS LL
Opening Report SSSS OU
Closing Report SSSS CU
Test Report SSSS T
Program Altered SSSS P0
Duress SSSS DD
Event 4 + 2 Report
Alarm Restore SSSS R C
Trouble Restore SSSS TR C
Bypass Restore SSSS B
AC Fail Restore SSSS E
Low Battery SSSS L L
Low Battery Restore SSSS L
Section
14.3.1
14.3.1
14.3.1
14.3.1
14.3.1
14.3.1
14.3.1
15.7
15.15
15.17
15.8
15.9
15.10
15.11
15.19
15.21
18.5
15.3
15.2
15.1
15.13
H
H
H
C
B
O
E
0
H
H
C
R H
A
R CR
B
BR
43
