Disassembly Procedures
!
Note: If the fit between the right hinge ball and the lid is
so tight you cannot press it into position with the
right thumb, carefully strike the right corner of the
lid with the palm of the hand to snap it into
position.

Front Panel

1. Disconnect power supply to unit.
2. Remove two T-25H Torx screws securing front panel.
3. Pull front panel up and away from the bottom.

Top Cover

1. Disconnect power supply to unit.
2. Remove Front Panel.
3. Remove two top cover bolts and tilt Top Cover back.
Note: Hold lid closed or tape lid to the Top Cover to
prevent it from striking the Control Panel.
22
WARNING
16022842 Rev. 0
To avoid risk of electrical shock, personal injury or death;
disconnect power to unit before servicing.

Tub Cover

1. Disconnect power supply to unit.
2. Secure Lid to the Top cover.
3. Remove Front Panel.
4. Remove screw securing Top cover to the cabinet.
5. Tilt Top backwards.
6. Remove tub cover by unsnapping the tabs securing
Tub Cover to the Outer Tub.

Balance Ring

1. Disconnect power supply to unit.
2. Remove Tub Cover.
3. Insert a pencil or other small pin through the three
small holes in the outer tub depressing the tabs on
the Balance Ring.
