General Information

Model Identification

Model and serial number is located on the back of the
console and cabinet. It is important that you keep a
record for future reference.
• For Maytag product call your distributor or visit the
Web Site at www.maytagcommerciallaundry.com
When contacting provide product information located on
rating plate. Record the following:
Model Number:
Serial or S/N Number:
Date of purchase:
Distributor name and address: ___________________
Commercial Washer Nomeclature
M
Brand
M - Commercial Maytag
Product Type
AT - Automatic Vertical
12 - Top Load Regular Tub
13 - Top Load Deep Tub
©2003 Maytag Appliances Company
___________________
___________________
___________________
AT 12 PD
Model Number
Control Type
CS - Mechanical coin slide ready
MN - Mechanical non-coin
PD - Microprocessor with coin drop
PN - Microprocessor non-coin
PR - Microprocessor debit reader ready
PS - Microprocessor coin slide ready
16022842 Rev. 0
Service
Keep a copy of sales receipt for future reference or in
case warranty service is required. To locate an authorized
distributor:
• For Maytag product call your distributor or visit the
Web Site at www.maytagcommerciallaundry.com.
Service should be performed by qualified service
technicians. We also recommend contacting an
authorized distributor, if service is required.
Parts and Accessories
Purchase replacement parts and accessories over the
phone. To order accessories for your product call:
• or Maytag product call your distributor or visit the Web
Site at www.maytagcommerciallaundry.com.
Only factory approved replacement parts should be used.
A A
W - White
Q - Bisque
A - 120V 60Hz
B - 120V 60Hz (Canada)
G - 220 / 240V 50Hz (Generic Europe)
E - 220 / 240 50Hz (U.K. Export)
Marketing Code
This identifies which
version of production
the unit is
W
Color Code
Voltage Code
7
