5.1.2
Using HBAnyware Utility
This product name displayed in HBAnyware Utility/NT is "BX600FC42E - -
10:00:**:**:**:**:**:**".
The "**:**:**:**:**:**" shows the IEEE address of the 4Gbit/s FC I/O Module. Each 4Gbit/s FC I/
O Module has a unique IEEE address, which is written on the sticker on each 4Gbit/s FC I/O Module.
For PG-FCD201, there are two adapters and two IEEE Addresses. Due to this there are two IEEE
address labels.
1
Click the "Start" button
"Emulex"
2
Select the local server, and click the "Driver Parameters" tab.
If the setting value varies for each adapter, select the adapter to be set, and click [Driver
Parameters].
• When selected the local server and "Driver Parameters" (common setting for all adapters)
For PG-FCD201, two BX600-FC42E are displayed.
68
"HBAnyware" in this order.
When adding this product after installation, the settings for the existing product
may be changed. Therefore, after adding this product or driver, check the detailed
settings and correct them if necessary.
"Programs" or "All Programs"
