4.3.2
Using HBAnyware Utility
This product name displayed in HBAnyware Utility is "BX600-FC42E - 10:00:**:**:**:**:**:**".
The "**:**:**:**:**:**" shows the IEEE address of the 4Gbit/s FC I/O Module. Each 4Gbit/s FC I/
O Module has a unique IEEE address, which is written on the sticker on each 4Gbit/s FC I/O Module.
1
Click the "Start" button
"Emulex"
2
Select the target 4Gbit/s FC I/O Module, and click the "Firmware"
tab.
For PG-FCD201, two BX600-FC42E are displayed.
3
For the firmware version, check the "Current Firmware Version:"
value in "Firmware".
• When the version is "2.70x6", proceed to Step 8.
• When the version is other than "2.70x6", proceed to Step 4.
4
Click "Update Firmware..." in "Firmware".
When the confirmation dialog appears, click [Yes].
5
Insert the driver disk (CD-ROM) into the CD-ROM drive, select the
Firmware file in the CD-ROM drive, and click [Start Download].
6
When the Firmware update is completed, click [Close].
7
Check that the "Current Firmware Version:" value in "Firmware" is
"2.70x6".
60
"HBAnyware" in this order.
[CD-ROM drive]:\FirmBIOS\zf2.70x6.all
"Programs" or "All Programs"
