4
Select the adapter for which settings are changed from the
adapter list on the left of the window, and double-click "Topology"
in "Parameters".
When there are two or more adapters, refer to "Appendix A How to Identify the Adapter"
( pg.74).
5
Set a value for "New Value" depending on the connection type,
check "Permanent", and click [Change].
When the connection type varies for each adapter, remove the check from the "Global"
checkbox.
Connection type
FC-AL
Fabric
• When all the installed adapters are FC-AL connection:
• When only the adapter under setting is Fabric connection:
6
Double-click "QueueDepth" in "Parameters".
64
New Value
0
1
