Chapter 4
4.4

Diagnostic Mode

Diagnostic Mode temporarily powers the printer using factory default parameters while
printing out the printer's current configuration on what is called the Status Label. This
information is used to help diagnose and troubleshoot printer configuration issues. The
default baud rate is set to 9600 and is used when entering the diagnostic mode. The printer
continues using the factory default parameters until printer power is cycled. The printer will
then return to the previous configuration in use before entering the diagnostic mode.
4.4.1

Entering Diagnostic Mode

To enter the diagnostic mode, press and hold the print button in while turning on the printer.
Release the button after the status light indicator starts to blink and the printer will power up
into diagnostic mode.
4.1.2

Status Label

The printer will print the Status label after the printer performs a power-up and enters the
diagnostic mode. The status label prints out the reports generated by the ^D323), ^D326),
^D325), and ^D324) commands followed by the print head test pattern.
326M User's Guide
Figure 10 ^D960)1 or ^K Test Pattern
Enablements (D323 or <Ctrl> Y)
User Interface
Software flow control:
Hardware flow control:
Operational
Auto power-up script:
Auto enquiry after print:
Auto media sizing:
Auto top-of-form alignment:
Auto alignment after error:
Auto acknowledge after cmd:
Auto respond after error:
Cutter:
Printed Media Handler PMH:
Figure 11 ^D323-List Enablements Example
Printer Modes
(D770) enabled
(D771) disabled
(D720) disabled
(D721) disabled
(D722) disabled
(D723) disabled
(D724) disabled
(D726) disabled
(D727) disabled
(D740) disabled
(D741) disabled
27
