Chapter 3
3.4

Loading Media

The open frame printers have been designed to make loading media a simple process. No
adjustments are required when installing media once the media guides are set, thus
reducing down time. Contact your Microcom Corporation Representative about the
availability of custom size media guides. Follow the instructions below to properly load the
media.
1. Tear off a clean edge on the media before loading into the printer.
2. Insert the media into the media path (see Figure 6), located on the back of the
printer, until you feel resistance.
3. Push and hold the FEED button to feed the media through the printer.
4. Once the media exits the front of the printer, release the button.
326M User's Guide
Media Path
Figure 8 Loading Media (426M)
Getting Started
FEED button
13
