Chapter 3
3.2.2 Communication Interface
The printers may be interfaced to PC's, mini-computers, main frames, and special purpose
machines. The 326M and 426M printers offer a standard RS-232 serial port, USB (version
1.1), and 10BASE-TX Ethernet as standard communication interface.
10 BASE T
Ethernet Port
Figure 5
Cutter
326M User's Guide
USB
Port
Communication Connections (426M)
LPD /
INPUT 2
Figure 6 Optional Component Connections
RS-232
Serial Port
Remote INPUT 1
Button
Getting Started
INPUT 3
9
