Figure 12 ^D326-List Settings Example - Microcom 326M User Manual

Direct thermal printers
Table of Contents

Advertisement

Printer Modes
28
Settings (D326 or <Ctrl> V)
Operational
Print Speed:
Detector mode:
Slew Speed:
Darkness:
Retraction delay:
Print delay:
Labels printed:
Distances
Label width (LSX):
Label height (LSY):
Reg. mark height (GAP):
To reg'n mark (DRM):
X offset (OFX):
Y offset (OFY):
Dist. Past Gap (DPG):
Activate Gap Det (AGD)
Advance/retract:
Roll diam. ref. length:
Black line det to head:
Gap det to head:
Printhead
Width:
Resolution:
Serial port settings
Ethernet
MAC:
Internet Protocol
Printer port number:
Printer addr:
Server/Host addr:
Gateway addr:
Broadcast addr mask:
Net addr mask:
Parallel port settings:
USB port settings
Thresholds
Gap:
Black line:
Stock:
High head temperature:
Low head temperature:
PWM periods
Gap:
Black line:
Label Present:
Stacker:
NOTE: Some items may not be correct until after a scripted
label has been printed or Auto-size (D310) has been run.
Figure 12
^D326-List Settings Example
(D635) 6.0 ips
(D636) 0 (none)
(D645) 6.0 ips
(D690) 75 (Dark)
(D641) 0.5 sec.
(D640) 0.0 sec.
(D655) 42
(D631) 3.34 inches
(D632) 1.5.12 inches
(D633) 0.148 inches
(D634) 0.0 inches
(D637) 0.0 inches
(D638) 0.0 inches
(Auto)
1.225 inches
(Auto)
0.0 inches
(D642) 0.512 inches
(D646) 10.0 inches
(D648) 2.32 inches
(D649) 2.34 inches
(D647) 4.094 inches
(D647) 203 dpi
(D670) 9600,N,8,1
Active at 10/100
0x000257795634
(D674) 23
(D675) 192.168.200.3
(D676) 192.168.200.1
(D677) 192.168.200.1
(D678) 192.168.200.255
(D679) 255.255.255.0
Not installed
Not installed
(D680) 30
(D681) 120
(D682) 110
147
24
12
41
64
64
326M User's Guide
Chapter 4
