Integrated Pci Ide; Integrated Sound; Integrated Lm79; Keyboard Detection - Intergraph InterServe 80 SL System Setup

Parallel Port
This setting configures the operation of the parallel port. Select Disable (to disable the
selected port), Enable (to allow user configuration of the selected port), Auto (to enable BIOS
or OS configuration) or OS Controlled (to allow the operating system to manage the port
configuration). The default setting is Auto.
Mode
The parallel port may be set for Output (AT), Bi-directional (PS/2), Extended Capabilities
Port (ECP), or Enhanced Parallel Port (EPP). The default setting is ECP.
Floppy Disk Controller
This setting configures the operation of the floppy disk controller. Select Disabled (no
configuration), Enabled (allows user configuration), Auto (to enable the BIOS or OS to set
the configuration), or OS Controlled (to allow the operating system to control the
configuration).

Integrated PCI IDE

This setting enables or disables the integrated PCI IDE adapter. The IDE controller may be
set for Primary, Both, or Disabled. The default setting is Both.

Integrated Sound

This setting enables or disables the integrated sound interface. The default setting is
Enabled.

Integrated LM79

This setting controls the integrated LM79 microprocessor system hardware monitor. The
LM79 can be used to monitor temperatures, power supply voltages and fan speeds. The
default setting is Enabled.

Keyboard Detection

Setting this parameter to Enabled activates keyboard detection when the system is started. If
this parameter is enabled, the system will not start without a keyboard. Disable this
parameter to allow the system to boot without a keyboard attached. The default setting is
Enabled.
45
