7. Under Objects/Adapter/Ultra SCSI, ensure the Ultra SCSI is enabled.
8. Restart the system.

Additional RAID Disk Drives Configuration

If your system was shipped with more than three RAID drives, then the extra drives are not
configured into an array. The InterServe 80 SL accommodates up to four 1.6-inch drives, or
up to five 1.0-inch drives. Before you can use them, these additional RAID drives must be
configured using the MegaRAID BIOS or, more preferrably, Power Console. The following
steps provide the general guidelines. For every possible configuration, refer to InterRAID
documentation for detailed instructions.
To configure additional drives:
1. Start the MegaRAID Power Console utility from the MegaRAID program group.
2. From the Adapter menu, select the Configuration submenu, then select the Custom
Configuration option.
3. Select the unconfigured RAID drives (shown as "READY") and configure them into one
or more arrays.
4. When the configuration has been applied, the Create Logical Drive dialog displays. Set
the logical drive options to your desired settings.
NOTE Before you select Apply, note the amount of disk space displayed. If this amount changes
when you select Apply, select Apply again to ensure the changes take effect.
5. Select Apply, and then select OK to save the configuration and initialize the drives.
If your system was shipped with FOPT2300 Split Channel SCSI cable and more than three
drives installed, they will be connected as indicated in the table below.
No. of Drives
Three
Four
Five
Channel 0 Channel 1
2 1
2 2
2 3
