NV name
field name
nciFcuConfig
DI1_config
nciFcuConfig
fan_config
nciFcuConfig
output_mode[0]
nciFcuConfig
output_mode[1]
Table C2. Configuration Variables for Excel 10 FCU Controllers
digital
engineering units:
state
English (metric) or states
or
plus range
value
BYTE
DI_WINDOW_CLOSED
0
DI_OCCUPIED_SENSOR
1
DI_AIR_FLOW
2
DI_CHANGEOVER_COOL
3
DI_WINDOW_OPEN
4
DI_UNOCCUPIED_SENS
5
DI_NO_AIR_FLOW
6
DI_CHANGEOVER_HEAT
7
DI_MOVEMENT
8
DI_NO_MOVEMENT
9
DI_NOT_USED
255
BYTE
NO_FAN
0
ONE_SPEED
1
TWO_SPEED
2
THREE_SPEED
3
BYTE
OUTP_COOLING
0
OUTP_HEATING
1
OUTP_CHANGEOVER
2
OUTP_NOT_USED
255
BYTE
OUTP_COOLING
0
OUTP_HEATING
1
2
OUTP_CHANGEOVER
OUTP_NOT_USED
255
EXCEL 10 FCU CONTROLLER LNS PLUG-INS USER GUIDE
default
DI_NOT_USED
This configuration variable specifies the digital input function and type
of switch. The option to be selected is the one which is the condition for
a closed switch contact (e.g., normally-closed window switch contact =
DI_WINDOW_CLOSED, normally-open window switch contact =
DI_WINDOW_OPEN).
DI_MOVEMENT and DI_NO_MOVEMENT are supported starting with
FCU2 version 1.0.3. These configuration settings cause the controller
to retain the occupied state for 15 minutes after the last movement is
detected.
THREE_SPEED
This configuration variable specifies the type of fan connected to the
controller.
OUTP_HEATING
This configuration variable specifies the operating mode of the output
1.
OUTP_COOLING
This configuration variable specifies the operating mode of the output
2. This setting is ignored for nciNumValve = TWO_PIPE.
41
comments
EN2B-0285GE51 R0909
