RuggedBackbone™ RX1501
Installation Guide

Technical Specifications

Section 4.1

Power Supply Specifications

Table 15: Power Supply Specifications
Power
Supply Type
HI
HIP
24
24P
48
48P
a
Power consumption varies based on configuration.
b
(T) denotes time-delay fuse.
Section 4.2

Critical Alarm Relay Specifications

Table 16: Form C Contact Relay Specifications
Power Supply Specifications
Input Range
Min Max
88 VDC 300 VDC
85 VAC 264 VAC
88 VDC 300 VDC
85 VAC 264 VAC
10 VDC 36 VDC
10 VDC 36 VDC
36 VDC 72 VDC
36 VDC 72 VDC
Voltage
30VDC
250VAC
Internal Max. Power
Fuse Rating Consumption
b
2A(T) 65W Max
b
2A(T) 65W Max
b
2A(T) 52W Max
b
2A(T) 52W Max
b
2A(T) 52W Max
b
2A(T) 52W Max
Technical Specifications
Max Power
Connections
a
Output
50W
terminal block
Pluggable
50W
terminal block
42W
terminal block
Pluggable
42W
terminal block
42W
terminal block
Pluggable
42W
terminal block
Current
5A
6.25A
Chapter 4
Screw
Screw
Screw
33
