3 Technical Specifications

3.1 Operating Environment

Parameter
Ambient Operating Temperature
Ambient Relative Humidity
Ambient Storage Temperature
IP Rating
Operating Altitude

3.2 Power Supply Specifications

Power Supply Type
12 – 24 VDC
24 VDC
48 VDC
HI (125/250 VDC) 1
HI (110/230 VAC) 1
NOTES:
1. This is the same power supply for both AC and DC.
2. (T) denotes time-delay fuse
3. For continued protection against risk of fire, replace only with same type and rating of fuse.

3.3 Failsafe Relay Specifications

Parameter
Max Switching Voltage
Rated Switching Current
NOTES:
1. Resistive Load.
2. For Class-2 circuits only.
©
2008 RuggedCom Inc. All rights reserved
Range
-40 to 85°C
5% to 95%
-40 to 85°C
IP67
0 to 15240m (0 to 50000 ft)
Minimum Maximum
Input Input
10 VDC 36 VDC
18 VDC 36 VDC
36 VDC 72VDC
88 VDC 300 VDC
85 VAC 265 VAC
30VAC, 80VDC
0.3A @ 30VAC
1A @ 30VDC, 0.3A @ 80VDC
20
Comments
Ambient Temperature as
measured from a 30 cm radius
surrounding the center of the
M969 enclosure.
Non-condensing
Over temperature range of -40
Fuse
Isolation
Rating
3.15A (T) 1.5 kV DC
3.15A (T) 1.5 kV DC
3.15A (T) 1.5 kV DC
4 kV AC 5.5
3.15A (T)
kV DC
Value
to 85°C
Maximum Power
Consumption
10W
Rev104
