RuggedBackbone™ RX1501
Installation Guide

Product Overview

Section 1.1

Functional Overview

The RuggedBackbone™ RX1501 is a cost-efficient, rugged layer 3 switch and router. The RX1501's modular
and field replaceable platform allows you to select WAN, serial, and Ethernet options, making it ideally suited for
electric power utilities, the industrial plant floor, and traffic control systems.
The RX1501 is designed to the RuggedRated™ specification, providing a high level of immunity to
electromagnetic interference (EMI) and heavy electrical surges typical of the harsh environments found in many
industrial applications. An operating temperature range of -40°C to +85°C (-40°F to +185°F) allows the RX1501 to
be placed in almost any location.
Section 1.2

Feature Highlights

Cyber Security Features
• Multi-level passwords
• SSH/SSL encryption
• Enable/disable ports, MAC-based port security
• Port-based network access control (802.1x)
• VLAN (802.1Q) to segregate and secure network traffic
• RADIUS centralized password management
• SNMPv3 encrypted authentication and access security
RuggedRated™ for Reliability in Harsh Environments
• Immunity to EMI and high voltage electrical transients:
○ Zero-Packet-Loss Technology
○ Meets IEEE 1613 (electric utility substations)
○ Exceeds IEC 61850-3 (electric utility substations)
○ Exceeds IEC 61800-3 (variable speed drive systems)
○ Exceeds IEC 61000-6-2 (generic industrial environment)
• -40°C to +85°C operating temperature (no fans)
• Optional conformal coated printed circuit boards
• Failsafe Output Relay: For critical failure or error alarming
Functional Overview
Chapter 1
Product Overview
1
