RuggedBackbone™ RX1501
Installation Guide
Feature
USB
Video
LED Indications
Contols
Temperature Range
Power Requirements
Software Platform
Section 4.7

Mechanical Specifications

Table 24: Mechanical Specifications
Parameter
Dimensions
Weight
Ingress Protection
Enclosure
Mechanical Specifications
APE1402 APE1402W7
2 x USB 2.0, maximum combined USB device power consumption 500 mA at 5 V
Intel 4108 Grpahics Processor, DVI-D
Power and Disk
Momentary contact reset button
-40C to 70C
12W with no USB load, 14.5W with full USB load
Debian Linux® Windows®
Embedded Standard
7
1.74 × 17.36 × 11.9 inches
44.20 × 440.94 × 302.26 mm
Approximately 10.3 lbs (4.7 kg)
APE1404
Debian Linux®
Value
IP40
Aluminum
Technical Specifications
APE1404W7 APE1404CPK
Windows® Check Point GAiA™
Embedded Standard OS
7
Comments
(Height × Width × Depth)
Weight dependent on module selection.
