3 Technical Specifications

3.1 Operating Environment

Parameter
Ambient Operating Temperature
Ambient Relative Humidity
Ambient Storage Temperature

3.2 Power Supply Specifications

Power Supply Type
12 – 24 VDC
24 VDC
48 VDC
HI (125/250 VDC) 1
HI (110/230 VAC)
1
NOTES:
1. This is the same power supply for both AC and DC.
2. (F) Denotes fast-acting fuse, (T) denotes time-delay fuse
3. For continued protection against risk of fire, replace only with same type and rating of fuse.

3.3 Failsafe Relay Specifications

Parameter
Max Switching Voltage
Rated Switching Current

3.4 Data Port Specifications

Data Port
10/100 Mbps*
*Available as an option on RS1600
©
2008 RuggedCom Inc. All rights reserved
Range
-40 to 85°C
5% to 95%
-40 to 85°C
Input Range
Min Max
10 VDC 36 VDC
18 VDC 36 VDC
36 VDC 59 VDC
88 VDC 300 VDC
85 VAC 265 VAC
30VAC, 80VDC
0.3A @ 30VAC
1A @ 30VDC, 0.3A @ 80VDC
Media
Cat 5 UTP
measured from a 30 cm radius
surrounding the center of the
Fuse
Isolation
Rating
6.3A(F) 2 1.5 kV DC
5A(F) 2 1.5 kV DC
2A(T) 2 1.5 kV DC
4 kV AC 5.5
2A(T) 1,2
kV DC
Value
Distance
100m
19
Comments
Ambient Temperature as
RS1600 enclosure.
Non-condensing
Max. Power Consumption
RS1600 RS1600T
30 W 21 W
Connector Type
RJ45
Rev104
RS1600F
34 W
