Specifications

Ethernet Connections
10/100 BaseT, Auto Negotiation, Auto-Cross, Flow Control, 1916 MTU, Broadcast
Storm Protection, Full Line-Rate Forwarding.
Input Specifications
DC terminal 7 to 50 VDC, 1-0.1A
DC Terminal 12 to 48 VDC (Telco Compatible*)
(Telco Model)
DC jack 5 to 24 VDC
PoE When IE-MiniMc LFPT uses PoE technology to be a PD, the
maximum supply voltage is 50V
* Telco compatible 48 VDC allows for an absolute maximum voltage of 56.5 VDC.
AC Wall Adapter
100 to 240 ±10% VAC input, 5 VDC output, 2A max.
Operating Temperature
-40°F to +185°F (-40°C to +85°C) DC configuration
+14°F to +122°F (-10°C to +50°C) with AC wall adapter
Storage Temperature
-40°F to +185°F (-40°C to +85°C)
Humidity
5 to 95% (non-condensing); 0 to 10,000 ft. altitude
Dimensions
0.83"H x 1.80"W x 3.35"D (2.11 x 4.57 x 8.51 cm)
