Specifications for the PoE Giga-McBasic

Multi-mode 1300nm Dual Fiber
Single-mode 1310nm 1550nm Dual Fiber
Single-mode 1310nm 1490nm Single-Strand Fiber
Single-mode 1310nm 1550nm Single-Strand Fiber
Copper 10/100/1000Mbps
Ethernet Connections
10/100/1000 BaseT
Auto Negotiation
AutoCross
Flow Control
10240 MTU
Full Line-Rate Forwarding
Input Specifications
100 to 240 ±10% VAC input, 50/60 Hz, 0.5A to 0.2A
Operating Temperature
+32°F to +122°F (0°C to +50°C)
Storage Temperature
-40°F to +185°F (-40°C to +85°C)
Humidity
5% to 95% (non-condensing); 0 to 10,000 ft. altitude
Dimensions
1.46" H x 4.76" W x 7.32" D (3.71 x 12.09 X 18.59 cm)
Power Characteristics
Consumes less than 10 watts (heating) plus PSE power
IEEE802.3af Power to field < 15.5 watts
Standards Compliance
IEEE 802.3af Power Over Ethernet
IEEE 802.3 Ethernet Standards
IEEE 802.3u Auto-Negotiation
RFC-2474
RFC-2475 DiffServ QoS
7
