About the IE-MiniMc LFPT and Telco/LFPT Versions
The IE-MiniMc LFPT and Telco/LFPT Industrial Ethernet miniature media converter
features 10/100 switching copper-to-fiber conversion, miniature size, plug-and-play
operation, and as a PD device, is compliant to the IEEE 802.3af Power Over Ethernet
(PoE) standard. The IE-MiniMc LFPT and Telco/LFPT supports an extended voltage
range as well as extended operating temperature.
The feature Link Fault Pass Through (LFPT) is permanently enabled on the media
converter to assist the customer in troubleshooting.
Installing IE-MiniMc LFPT and Telco/LFPT
The IE-MiniMc LFPT and Telco/LFPT installs virtually anywhere as a standalone
device in locations with extremely limited space. Installation options include:
•
Velcro strips
•
DIN rail mounting with DIN Rail clips
•
A wall mount bracket
•
A PowerTray/18 for high density applications
Hardware Mounting Options
The IE-MiniMc LFPT and Telco/LFPT can be mounted on a DIN rail or using wall
mount brackets (shown below).
DIN rail clips (part number 806-39105) and wall mount brackets (part number 895-
39229) are available for purchase through an IMC Networks Distributor.
The DIN Rail clips include screws, to allow the
installation onto a DIN Rail. Install the screws
into DIN Rail clips, which should be mounted
parallel or perpendicular to the DIN Rail. Snap
the converter onto the clips. To remove the
converter from the DIN Rail, use a flat-head
screwdriver into the slot to gently pry the
converter from the rail.
1
